Lifting Solutions

Eye & Eye Webbing Slings for Heavy Lifting

liftrue | Manufacturer & Supplier

Reinforced eye & eye flat webbing sling with high-tenacity polyester construction and color-coded WLL identification.

Key Features

  • Reinforced eyes with wear-resistant stitching for longer service life
  • Available with custom lengths, widths, and private labeling
  • Color-coded WLL identification per EN 1492-1 for instant capacity recognition on site
  • Low elongation under 3% at rated load for precise load positioning
  • Soft polyester construction protects painted, polished, and coated surfaces from scratches
  • Compliant with EN 1492-1 | EN 1492-2

Applications

General purpose lifting Steel pipes & profiles Machinery & equipment Concrete & cement products

Own Manufacturing Facility

ODM / OEM & Flexible MOQ

Fast Response & Delivery

ISO 9001 & CE certified

Trusted by 500+ Clients

FAQ

Eye & Eye Webbing Slings FAQs

They are ideal for general lifting, steel pipes, machinery, and concrete products where a flat, soft surface protects the load. The reinforced eyes fit hooks and shackles securely.

Double-ply slings use two layers of webbing for higher capacity and better resistance to cutting and abrasion in demanding applications. Single-ply is lighter and more flexible for general use.

Our webbing slings are manufactured to EN 1492-1 / EN 1492-2 with CE marking. Batch test reports, MTC, and inspection certificates are available for quality documentation.

Reinforced eyes distribute stress at the hook contact point and use wear-resistant stitching to prevent fraying, extending sling life in repeated lifting cycles.

Add a protective sleeve when lifting loads with sharp edges, rough surfaces, or abrasive corners. The sleeve absorbs wear and protects the load-bearing webbing underneath.

Check both eyes for cuts, broken stitches, abrasion, or chemical damage. Verify the WLL label is legible and matches the lift plan. Retire when in doubt: slings are cheap, the load (and lives) they protect are not. Withdraw immediately if you see cuts, abrasion, chemical damage, heat marks, missing labels, or any structural deformation.

Standard eyes are folded and sewn with reinforced wear patches. We can also supply flat eyes, tapered eyes, or eyes with additional protective webbing based on your hardware and application.

Specifications

Technical Specifications

Eye & Eye Webbing Sling Specifications

WLL (kg) Thick. (mm) Width 6:1 (mm) Width 7:1 (mm) Min L (m) Max L (m) Annular L (mm) Wt 6:1 (kg/m) Wt 7:1 (kg/m)
1000 7.5 25 30 0.8 100 300 0.20 0.22
2000 50 60 1.0 300 0.41 0.45
3000 75 90 1.0 350 0.60 0.71
4000 100 120 1.5 500 0.75 1.02
5000 125 150 1.5 550 1.02 1.21
6000 150 180 1.5 600 1.06 1.42
8000 200 240 2.0 700 1.69 1.89
10000 250 300 2.0 800 2.07 2.34
12000 300 300 2.0 900 2.17 2.98

Safety

Eye & Eye Webbing Sling Safety & Usage Guidelines

1
Inspect the webbing body, reinforced eyes, and stitching for cuts, abrasion, broken yarns, or missing labels before each lift
2
Check eye reinforcement stitching — eye-to-body junction is the highest stress area; reject if the eye shows stitch separation or elongation
3
Never exceed the working load limit (WLL) marked on the identification tag; webbing slings are color-coded by WLL per EN 1492-1
4
Apply the correct hitch factor: 100% vertical, ~75–80% choker, up to 200% basket — recalculate effective WLL before each lift
5
Place the flat webbing against the load surface to use the wide bearing face — never bunch or twist the webbing into a narrow rope-like contact
6
Use protective sleeves or corner pads on sharp edges; flat webbing cuts more easily than round slings when dragged over a sharp edge
7
Do not tie knots or join two slings by threading eyes through each other — use shackles or connecting hardware sized to the eye
8
Operating temperature range: -40°C to 100°C for polyester; keep away from welding arcs, molten splatter, and chemicals (acids, alkalis)
9
Retire immediately if you see cuts crossing more than 10% of webbing width, chemical attack, heat marks, missing tags, or any structural deformation

All liftrue products are manufactured under ISO 9001 quality management and are CE certified.
